High-voltage traction inverter

With both battery electric vehicles (BEV) or plug-in hybrid electric vehicles (PHEV), transferring the stored energy from the high-voltage (400 / 800 V) battery to the electric motors used to drive the wheels is the job of the high-voltage traction inverter. Traction inverters currently come in all shapes and sizes, ranging from 50 kW up to more than 500 kW with currents of several hundred amps. So safe and efficient DC to AC conversion is critical. In addition a small efficient traction inverter using GaN FETs can help eliminate the high-frequency whine associated with many battery powered vehicles.

功能框图

Highlighted components are Nexperia focus products

设计考虑因素

  • 完整360度检测需要各种雷达选件和多个传感器,因此空间极为有限
  • 使用“邮票”雷达传感器模块以节省整个系统空间
  • 使用CFP和LFPAK封装以节省空间、提高热效率和系统稳健性
