NEVB-LOGIC01 footprint adapter board

NEVB-LOGIC01 is a dual in-line logic footprint adapter board, designed to simplify the evaluation of Nexperia logic devices by offering several package footprints.

NEVB-LOGIC01 footprint adapter board

Key features & benefits

• Plug and play: identify the package you will be using, place the device in the footprint and solder the device down to start evaluating
• Compatible with several packages:

TSSOP14/16
TSSOP20
TSSOP24
DHVQFN14/16
DHVQFN20
DHVQFN24
QFN12
