主要特性和优势
- 30 kV ESD保护
- 系统抗ESD能力更强
- 卓越的ESD钳位特性
- 钳位电压低以及响应速度快,提供优化的保护
- 高峰值脉冲功率(8/20 μs)性能
- 整体功耗因超低泄漏电流而降低
- 超低泄漏电流
- 器件电容值低,可避免意外的电路干扰
- 低器件电容值
关键应用
- 汽车总线保护
- 数据与音频接口,如汽车多媒体线路保护
- 过压保护,如安全气囊控制器、ABS、ESC
- 汽车驾驶接口保护,如仪表板
参数搜索
产品
型号 | 描述 | 状态 | 快速访问 |
---|---|---|---|
BZA800A-series | Quadruple ESD transient voltage suppressor | ACT |
|
BZA820A | Quadruple ESD transient voltage suppressor | EndOfLife | |
BZA856A | Quadruple ESD transient voltage suppressor | Production | |
BZA862A | Quadruple ESD transient voltage suppressor | Production | |
BZA868A | Quadruple ESD transient voltage suppressor | EndOfLife | |
BZA800AVL series | Quadruple low capacitance ESD suppressor | ACT |
|
BZA856AVL | Quadruple low capacitance ESD suppressor | Production | |
BZA862AVL | Quadruple low capacitance ESD suppressor | EndOfLife | |
BZA868AVL | Quadruple low capacitance ESD suppressor | EndOfLife | |
PESD3V3U1UA_UB_UL | ACT |
|
|
PESD3V3U1UA | Ultra low capacitance unidirectional ESD protection diodes | Production | |
PESD3V3U1UB | Ultra low capacitance unidirectional ESD protection diodes | Production | |
PESD3V3U1UL-Q | Ultra low capacitance unidirectional ESD protection diode | Production | |
PESD3V3U1UT | Ultra low capacitance ESD protection diode in SOT23 package | Production | |
PESD5V0L2UU; PESD6V0L2UU | Low capacitance unidirectional ESD protection diodes | ACT |
|
PESD6V0L2UU | Low capacitance unidirectional ESD protection diodes | Production | |
PESDxL5UF; PESDxL5UV; PESDxL5UY | Low capacitance unidirectional fivefold ESD protection diode array | ACT |
|
PESD3V3L5UF | Low capacitance unidirectional fivefold ESD protection diode array | Production | |
PESD3V3L5UY | Low capacitance unidirectional fivefold ESD protection diode arrays | Production | |
PESD5V0L5UF | Low capacitance unidirectional fivefold ESD protection diode arrays | Production | |
PESD5V0L5UY | Low capacitance unidirectional fivefold ESD protection diode arrays | Production | |
PESDxU1UT series | Ultra low capacitance ESD protection diode in SOT23 package | ACT |
|
PESD12VU1UT | Ultra low capacitance ESD protection diode in SOT23 package | Production | |
PESD24VU1UT | Ultra low capacitance ESD protection diode in SOT23 package | Production | |
PESD3V3U1UT | Ultra low capacitance ESD protection diode in SOT23 package | Production | |
PTVSxP1UP | 600 W Transient Voltage Suppressor | ACT |
|
PTVS11VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS12VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS13VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS14VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS15VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS16VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS17VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS18VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS20VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS22VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS24VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS30VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS33VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS36VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS3V3P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS40VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS43VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS45VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS48VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS51VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS54VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS58VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS5V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS60VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS64VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS6V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS6V5P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS7V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS7V5P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS8V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS8V5P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVSxP1UTP series | High-temperature 600 W Transient Voltage Suppressor | ACT |
|
PTVS10VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS11VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS12VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS13VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS14VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS15VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS16VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS17VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS18VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS20VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS22VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS24VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS26VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS28VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS30VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS33VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS36VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS3V3P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS40VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS43VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS45VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS48VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS51VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS54VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS58VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS5V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS60VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS64VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V5P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS7V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS7V5P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS8V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS8V5P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS9V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVSxS1UR-[1550] | 400 W Transient Voltage Suppressor | ACT |
|
PTVS10VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS11VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS12VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS16VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS18VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS20VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS22VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS3V3S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS40VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS43VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS45VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS48VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS51VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS5V0S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS60VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS6V5S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS7V0S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS7V5S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS8V0S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS8V5S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVSxS1UTR series-[1550] | High-temperature 400 W Transient Voltage Suppressor | ACT |
|
PTVS10VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS11VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS12VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS13VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS14VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS15VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS16VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS17VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS18VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS20VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS22VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS24VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS26VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS28VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS30VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS33VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS36VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS40VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS43VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS45VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS48VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS51VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS54VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS58VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS5V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS60VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS64VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS6V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS6V5S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS7V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS7V5S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS8V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS8V5S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PESD2CANFD27V-QC | ESD protection for in-vehicle networks | Production | |
PESD2CANFD27V-T | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27L-T | ESD protection for In-vehicle networks | Production | |
PESD2CAN | CAN bus ESD protection diode | NotForDesignIn | |
PESD4USB5B-TTS | ESD protection for high-speed interfaces | Production | |
PESD2CANFD27U-T | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27L-U | ESD protection for In-vehicle networks | Production | |
PESD2IVN24-U | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27U-QB | ESD protection for In-vehicle networks | Production | |
PESD4USB5U-TBS | ESD protection for high-speed interfaces | Production | |
PESD1ETH1G-LS | ESD protection for In-vehicle networks | Production | |
PESD2CANFD24U-U | ESD protection for In-vehicle networks | Production | |
PESD2ETH1G-T | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27V-U | ESD protection for In-vehicle networks | Production | |
PESD2CANFD24U-T | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27U-QC | ESD protection for In-vehicle networks | Production | |
PESD2USB3UX-T | Automotive infotainment ESD protection diode | Production | |
PESD4USB5B-TBS | ESD protection for high-speed interfaces | Production | |
PESD2CANFD24V-U | ESD protection for In-vehicle networks | Production | |
PESD2CANFD24L-T | ESD protection for In-vehicle networks | Production | |
PESD4USB5U-TTS | ESD protection for high-speed interfaces | Production | |
PESD1CAN | CAN bus ESD protection diode | NotForDesignIn | |
PESD1CAN-U | CAN bus ESD protection diode | NotForDesignIn | |
PESD2CANFD24V-QC | ESD protection for in-vehicle networks | Production | |
PESD2ETH100-T | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27V-QB | ESD protection for in-vehicle networks | Production | |
PESD2CANFD24U-QB | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27U-U | ESD protection for In-vehicle networks | Production | |
PESD2USB5UX-T | Automotive infotainment ESD protection diode | Production | |
PESD2CANFD24V-T | ESD protection for In-vehicle networks | Production | |
PESD1LIN | LIN-bus ESD protection diode | NotForDesignIn | |
PESD2CANFD24V-QB | ESD protection for in-vehicle networks | Production | |
PESD2USB3UV-T | Automotive infotainment ESD protection diode | Production | |
PESD2USB5UV-T | Automotive infotainment ESD protection diode | Production | |
PESD2CANFD24U-QC | ESD protection for In-vehicle networks | Production | |
PTVS6V5S1UR | 400 W Transient Voltage Suppressor | Production | |
PESD4USB3B-TTS | ESD protection for high-speed interfaces | Production | |
PESD2CANFD36LU-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB5UBTTS-Q | Extremely low capacitance unidirectional ESD protection diode array | Production | |
PESD4USB5BBTTS-Q | Extremely low capacitance bidirectional ESD protection diode array | Production | |
PESD4USB3BCTBR-Q | Extremely low capacitance bidirectional ESD protection diode array | Production | |
PESD2CANFD36VU-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB5UTBR-Q | ESD protection for high-speed interfaces | Production | |
PESD4USB3U-TBS | ESD protection for high-speed interfaces | Production | |
PESD4USB3BBTBS-Q | Extremely low capacitance bidirectional ESD protection diode array | Production | |
PESD2CANFD27UT-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3BTTS-Q | ESD protection for high-speed interfaces | Production | |
PESD4USB3U-TTS | ESD protection for high-speed interfaces | Production | |
PESD4USB3UBTTS-Q | Extremely low capacitance unidirectional ESD protection diode array | Production | |
PESD4USB3UBTBS-Q | Extremely low capacitance unidirectional ESD protection diode array | Production | |
PESD36VL1BL-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD4USB5BBTBS-Q | Extremely low capacitance bidirectional ESD protection diode array | Production | |
PESD4USB5UBTBR-Q | Extremely low capacitance unidirectional ESD protection diode array | Production | |
PESD4USB5UBTBS-Q | Extremely low capacitance unidirectional ESD protection diode array | Production | |
PESD2CANFD27UQB-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD36LT-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB5BBTBR-Q | Extremely low capacitance bidirectional ESD protection diode array | Production | |
PESD2CANFD24VQB-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3BTBR-Q | ESD protection for high-speed interfaces | Production | |
PESD2CANFD24UU-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3B-TBS | ESD protection for high-speed interfaces | Production | |
PESD2CANFD27VQC-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3UTTS-Q | ESD protection for high-speed interfaces | Production | |
PESD2CANFD24UQB-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3UTBR-Q | ESD protection for high-speed interfaces | Production | |
PESD4USB3UCTBR-Q | Extremely low capacitance unidirectional ESD protection diode array | Production | |
PESD2CANFD24UQC-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3BBTBR-Q | Extremely low capacitance bidirectional ESD protection diode array | Production | |
PESD4USB3BBTTS-Q | Extremely low capacitance bidirectional ESD protection diode array | Production | |
PESD2USB5UXT-Q | Automotive infotainment ESD protection diode | Production | |
PESD2CAN24LT-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD27UQC-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB5BTBS-Q | ESD protection for high-speed interfaces | Production | |
PESD2CANFD27VQB-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD24VQC-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD24VT-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD24VU-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3UTBS-Q | ESD protection for high-speed interfaces | Production | |
PESD2CAN24XLT-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB5UTBS-Q | ESD protection for high-speed interfaces | Production | |
PESD2IVN24U-Q | ESD protection for in-vehicle networks | Production | |
PESD4USB3BTBS-Q | ESD protection for high-speed interfaces | Production | |
PESD2USB3UVT-Q | Automotive infotainment ESD protection diode | Production | |
PESD2CANFD36UT-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD36UU-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD24UT-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD36VT-Q | ESD protection for in-vehicle networks | Production | |
PESD24VU2BT-Q | ESD protection for in-vehicle networks | Production | |
PESD27VU2BT-Q | ESD protection for in-vehicle networks | Production | |
PESD33VL1BL-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD30VL1BL-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD2USB3UXT-Q | Automotive infotainment ESD protection diode | Production | |
PESD30VL1BLS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD27VL2BAT-Q | ESD protection for in-vehicle networks | Production | |
PESD24VL2BAT-Q | ESD protection for in-vehicle networks | Production | |
PESD1CANFD36LS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD1CANFD33L-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD36VV2BT-Q | ESD protection for in-vehicle networks | Production | |
PESD24VL1BLS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD36VL1BLS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD1CANFD36L-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD24VL1BL-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD4USB5BTBR-Q | ESD protection for high-speed interfaces | Production | |
PESD1CANFD24L-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD1CANFD30LS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD75VX1BLS-Q | ESD protection for in-vehicle networks | Production | |
PESD2CAN24T-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD27VU-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD27UU-Q | ESD protection for in-vehicle networks | Production | |
PESD33VL1BLS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD4USB5UTTS-Q | ESD protection for high-speed interfaces | Production | |
PESD4USB5BTTS-Q | ESD protection for high-speed interfaces | Production | |
PESD2USB5UVT-Q | Automotive infotainment ESD protection diode | Production | |
PESD36VL2BT-Q | ESD protection for in-vehicle networks | Production | |
PESD1CANFD24LS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD27VV2BAT-Q | ESD protection for in-vehicle networks | Production | |
PESD24VV2BAT-Q | ESD protection for in-vehicle networks | Production | |
PESD36VU2BT-Q | ESD protection for in-vehicle networks | Production | |
PESD1CANFD30L-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD1CANFD33LS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD2ETH1GXT-Q | ESD protection for In-vehicle networks | Production | |
PESD1ETH1GXLS-Q | ESD protection for In-vehicle networks | Production | |
PESD1ETH1GLS-Q | ESD protection for In-vehicle networks | Production | |
PESD2CANFD27LU-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD27VT-Q | ESD protection for in-vehicle networks | Production | |
PESD2IVN27U-Q | ESD protection for in-vehicle networks | Production | |
PESD2ETH100T-Q | ESD protection for in-vehicle networks | Production | |
PESD1IVN27A-Q | ESD protection for In-vehicle networks | Production | |
PESD2CANFD24LT-Q | ESD protection for In-vehicle networks | Production | |
PESD2IVN27T-Q | ESD protection for in-vehicle networks | Production | |
BZA868AVL | Quadruple low capacitance ESD suppressor | EndOfLife | |
BZA820A | Quadruple ESD transient voltage suppressor | EndOfLife | |
BZA420A | Quadruple ESD transient voltage suppressor | Production | |
BZA456A | Quadruple ESD transient voltage suppressor | Production | |
BZA856A | Quadruple ESD transient voltage suppressor | Production | |
BZA462A | Quadruple ESD transient voltage suppressor | Production | |
BZA856AVL | Quadruple low capacitance ESD suppressor | Production | |
BZA862A | Quadruple ESD transient voltage suppressor | Production | |
BZA862AVL | Quadruple low capacitance ESD suppressor | EndOfLife | |
BZA408B | Quadruple bidirectional ESD transient voltage suppressor | Production | |
MMBZ16VZ-LS | TVS device for surge protection of interface and supply lines | Production | |
BZA868A | Quadruple ESD transient voltage suppressor | EndOfLife | |
MMBZ33VCL | Double ESD protection diode for transient overvoltage suppression | Production | |
MMBZ12VDL | Double ESD protection diode for transient overvoltage suppression | Production | |
PESD3V3S4UF | Unidirectional quadruple ESD protection diode arrays | Production | |
PESD3V3L4UF | Low capacitance unidirectional quadruple ESD protection diode arrays | Production | |
PESD1FLEX | FlexRay bus ESD protection diode | NotForDesignIn | |
PESD15VS1ULD | Unidirectional ESD protection diode | Production | |
PESD15VS1UL | Unidirectional ESD protection diode | Production | |
PESD1IVN27-U | ESD protection for In-vehicle networks | Production | |
PESD12VS1UL | Unidirectional ESD protection diode | Production | |
PESD24VV1BA | Bidirectional ESD protection diode | Production | |
PESD6V0L2UU | Low capacitance unidirectional ESD protection diodes | Production | |
PESD24VL2BT | Low capacitance double bidirectional ESD protection diode in SOT23 | NotForDesignIn | |
PESD1IVN24-LS | ESD protection for In-vehicle networks | Production | |
PESD24VS1UB | ESD protection diode in SOD523 package | Production | |
PESD27VV1BA | Bidirectional ESD protection diode | Production | |
PESD12VS1ULS | Unidirectional ESD protection diode | Production | |
PESD12VU1UT | Ultra low capacitance ESD protection diode in SOT23 package | Production | |
PESD12VS2UT | Double ESD protection diode | Production | |
PESD1IVN27-A | ESD protection for In-vehicle networks | Production | |
PESD2IVN27-T | ESD protection for In-vehicle networks | Production | |
PESD3V3L1UA | EndOfLife | ||
PESD1IVN27-LS | ESD protection for In-vehicle networks | Production | |
PESD15VS1ULS | Unidirectional ESD protection diode | Production | |
PESD2IVN27-U | ESD protection for In-vehicle networks | Production | |
PESD3V3T1BLS | Bidirectional ESD protection diode | Production | |
PESD1IVN-U | In-vehicle network ESD protection diode | NotForDesignIn | |
PESD1LVDS | ESD protection for in-vehicle ultra high-speed interfaces | Production | |
PESD5V0L4UF | Low capacitance unidirectional quadruple ESD protection diode arrays | Production | |
PESD2IVN24-T | ESD protection for In-vehicle networks | Production | |
PESD3V3U1UT | Ultra low capacitance ESD protection diode in SOT23 package | Production | |
PESD24VS1ULS | Unidirectional ESD protection diode | Production | |
PESD3V3L1UL | Low capacitance unidirectional ESD protection diode | Production | |
PESD3V3L1UB | Low capacitance unidirectional ESD protection diode | Production | |
PESD1IVN24-A | ESD protection for In-vehicle networks | Production | |
PESD12VV1BLS | Very low capacitance bidirectional ESD protection diode | Production | |
PESD24VS2UAT | Double ESD protection diode in SOT23 package | Production | |
PESD2CANFD24L-U | ESD protection for In-vehicle networks | Production | |
PESD3V3X1BL | Ultra low capacitance bidirectional ESD protection diode | Production | |
PESD5V0S1ULS | Unidirectional ESD protection diode | Production | |
PESD3V3S1ULS | Unidirectional ESD protection diode | Production | |
PESD3V3S1BL | Low capacitance bidirectional ESD protection diode | Production | |
PESD24VU1UT | Ultra low capacitance ESD protection diode in SOT23 package | Production | |
PESD3V3L5UF | Low capacitance unidirectional fivefold ESD protection diode array | Production | |
PESD5V0L2UM | Low capacitance double ESD protection diode | Production | |
PESD5V0L4UG | Low capacitance unidirectional quadruple ESD protection diode arrays | Production | |
PESD3V3L5UY | Low capacitance unidirectional fivefold ESD protection diode arrays | Production | |
PESD36VS1UL | Unidirectional ESD protection diode | Production | |
PESD5V0S1UA | Unidirectional ESD protection for transient voltage suppression | Production | |
PESD3V3L4UG | Low capacitance unidirectional quadruple ESD protection diode arrays | Production | |
PESD2IVN-U | In-vehicle network ESD protection diode | NotForDesignIn | |
PESD36VS1ULS | Unidirectional ESD protection diode | Production | |
PESD5V0U5BF | Ultra low capacitance bidirectional fivefold ESD protection array | Production | |
PESD5V0L2BT | Low capacitance double bidirectional ESD protection diode in SOT23 | NotForDesignIn | |
PESD5V0X1UAB | Ultra low capacitance unidirectional ESD protection diode | Production | |
PESD5V0V1BLS | Very low capacitance bidirectional ESD protection diode | Production | |
PESD5V0S1ULD | Unidirectional ESD protection diode | Production | |
PESD5V0S1UJ | Unidirectional ESD protection for transient voltage suppression | Production | |
PESD5V0L5UY | Low capacitance unidirectional fivefold ESD protection diode arrays | Production | |
PESD5V0X1UB | Ultra low capacitance unidirectional ESD protection diode | Production | |
PESD5V0X2UAMB | Ultra low capacitance unidirectional double ESD protection diode | Production | |
PESD5V0U1UL | Ultra low capacitance unidirectional ESD protection diode | Production | |
PESD3V3L2UM | Low capacitance double ESD protection diode | Production | |
PESD5Z12 | Low capacitance unidirectional ESD protection diodes | Production | |
PESD3V3V1BL | Low capacitance bidirectional ESD protection diode | Production | |
PESD5V0L1UL | Low capacitance unidirectional ESD protection diode | Production | |
PESD5V0S4UF | Unidirectional quadruple ESD protection diode arrays | Production | |
PESD5Z6.0 | Low capacitance unidirectional ESD protection diodes | Production | |
PESD5V0L5UF | Low capacitance unidirectional fivefold ESD protection diode arrays | Production | |
PESD8V0S1ULS | Unidirectional ESD protection diode | Production | |
PRTR5V0U2F | Ultra low capacitance double rail-to-rail ESD protection | Production | |
PTVS26VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PRTR5V0U2K | Ultra low capacitance double rail-to-rail ESD protection | EndOfLife | |
PESD5V0S2BQA | Protection against high surge currents in ultra small DFN1010D-3 package | Production | |
PESD5V0U4BF | Ultra low capacitance bidirectional quadruple ESD protection array | Production | |
PESD5V0V2BM | Very low capacitance bidirectional ESD protection diodes | Production | |
PTVS54VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS33VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS28VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS14VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS36VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS51VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS51VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS8V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS12VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS12VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS7V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS10VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS17VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS36VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS15VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS36VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS40VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS6V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS15VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS15VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS7V0S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS8V0S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS18VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS43VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS18VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS43VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS28VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS33VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS3V3P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS54VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS7V5P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V5P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS60VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS7V5S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS58VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS48VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS8V5P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS24VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS17VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS40VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS11VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS8V5S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS20VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS13VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS64VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS11VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS12VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS20VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS3V3S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS3V3P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS58VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS10VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS60VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS48VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS40VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS17VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS16VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS5V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS24VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS13VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS7V5P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS13VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS45VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS22VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS26VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS7V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS30VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS22VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS33VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS16VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS45VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS10VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS43VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS9V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS58VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS5V0S1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS64VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS6V5P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS51VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS40VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS48VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS54VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS8V5P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS51VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS45VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS8V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS64VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V5S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS5V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS5V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS7V0P1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS8V0P1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD5V0C1ULS-Q | Extremely low clamping unidirectional ESD protection diode | Production | |
PESD5V0C2UM-Q | Extremely low capacitance unidirectional ESD protection diode array | Production | |
PESD5V0C1BLS-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD2ETHAX-Q | Ultra low capacitance double rail-to-rail ESD protection diode | Production | |
PESD3V3L1ULS | Unidirectional ESD protection diode | Production | |
PTVS6V0S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PESD24VS2UAT-Q | Double ESD protection diode in SOT23 package | Production | |
PTVS11VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS16VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS16VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS43VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PESD5V0S1BA-Q | Bidirectional ESD protection diode | Production | |
PTVS8V5S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS24VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS11VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS20VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS18VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS14VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS30VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS30VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS60VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS7V5S1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS60VP1UP | 600 W Transient Voltage Suppressor | Production | |
PTVS48VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
NUP1301-Q | Ultra low capacitance ESD protection array | Production | |
PTVS24VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
NUP1301U-Q | Ultra low capacitance ESD protection array | Production | |
PESD3V3S4UD-Q | Quadruple ESD protection diode array | Production | |
PESD15VS1UB-Q | ESD protection diode in SOD523 package | Production | |
PESD15VS2UAT-Q | Double ESD protection diode | Production | |
PTVS15VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS54VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS30VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS15VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS28VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS14VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS8V5S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PESD12VL2BT-Q | Low capacitance double bidirectional ESD protection diode in SOT23 | Production | |
PESD5V0L1ULS | Unidirectional ESD protection diode | Production | |
MMBZ15VAT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PTVS12VS1UR | 400 W Transient Voltage Suppressor | Production | |
PESD24VL1BA-Q | Low capacitance bidirectional ESD protection diode in SOD323 | Production | |
PRTR5V0U2X-Q | Ultra low capacitance double rail-to-rail ESD protection diode | Production | |
PESD15VL2BT-Q | Low capacitance double bidirectional ESD protection diode | Production | |
MMBZ16VZLS-Q | TVS device for surge protection of interface and supply lines | Production | |
PTVS14VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS33VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS54VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD5V0F1BL-Q | Femtofarad bidirectional ESD protection diode | Production | |
PESD3V3L2BT-Q | Low capacitance double bidirectional ESD protection diode in SOT23 | Production | |
PESD12VS1UJ-Q | Unidirectional ESD protection for transient voltage suppression | Production | |
PESD5V0V1BA-Q | Very low capacitance bidirectional ESD protection diode | Production | |
PESD5V0X1BT-Q | Ultra low capacitance bidirectional ESD protection diode | Production | |
PTVS45VP1UP | 600 W Transient Voltage Suppressor | Production | |
PESD36VS2UT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PESD5V0U1UA-Q | Ultra low capacitance unidirectional ESD protection diode | Production | |
PTVS14VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD24VL2BT-Q | Low capacitance double bidirectional ESD protection diode in SOT23 | Production | |
NUP1301QA-Q | Ultra low capacitance ESD protection array | Production | |
PTVS40VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V0S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS58VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS18VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS5V0S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS64VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V0S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS7V0P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD5V0L1BA-Q | Low capacitance bidirectional ESD protection diode | Production | |
PESD5V0S5UD-Q | Fivefold ESD protection diode array | Production | |
PESD2CANFD36VQB-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PTVS14VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD5V0X2UM-Q | Ultra low capacitance unidirectional double ESD protection diode | Production | |
MMBZ16VTAL-Q | High surge current unidirectional double ESD protection diodes | Production | |
PTVS5V5D1BL-Q | Ultra compact transient voltage supressor | Production | |
PTVS51VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD5Z7.0-Q | Low capacitance unidirectional ESD protection diodes | Production | |
PESD2IVN24T-Q | ESD protection for In-vehicle networks | Production | |
PTVS18VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS22VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS40VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS45VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS36VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS51VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PESD5V0S4UD-Q | Quadruple ESD protection diode array | Production | |
PESD5V0S2UAT-Q | Double ESD protection diode in SOT23 package | Production | |
PTVS60VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD15VS2UT-Q | Double ESD protection diode | Production | |
PESD2CANFD33UQB-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD24VS4UD-Q | Quadruple ESD protection diode array | Production | |
PESD5V0L1ULD-Q | Low capacitance unidirectional ESD protection diode | Production | |
PESD12VS1ULD-Q | Unidirectional ESD protection diode | Production | |
PTVS36VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD5V0U1UB-Q | Ultra low capacitance unidirectional ESD protection diodes | Production | |
PTVS20VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS28VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS33VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS64VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD5V0U1BB-Q | Low capacitance bidirectional ESD protection diode | Production | |
MMBZ15VDL-Q | Double ESD protection diode for transient overvoltage suppression | Production | |
PTVS43VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS17VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS26VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS11VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS15VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS11VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD5V0X1ULD-Q | Ultra low capacitance unidirectional ESD protection diode | Production | |
PTVS16VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS51VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS20VP1UTP | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS22VS1UR | 400 W Transient Voltage Suppressor | Production | |
PTVS22VS1UTR | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS18VP1UP | 600 W Transient Voltage Suppressor | Production | |
PESD2IVN48T-Q | ESD protection for in-vehicle networks | Production | |
PESD5V0V1BB-Q | Very low capacitance bidirectional ESD protection diode | Production | |
PESD5V0U2BT-Q | Ultra low capacitance bidirectional double ESD protection diode | Production | |
PESD5V0L2BT-Q | Low capacitance double bidirectional ESD protection diode in SOT23 | Production | |
PTVS58VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS17VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS45VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS22VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS9V0P1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS28VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS13VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS10VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PESD5V0X2UAM-Q | Ultra low capacitance unidirectional double ESD protection diode | Production | |
PESD3V3U1UL-Q | Ultra low capacitance unidirectional ESD protection diode | Production | |
PESD1IVN24L-Q | Bidirectional ESD protection diode | Production | |
PESD1IVN27LS-Q | ESD protection for in-vehicle networks | Production | |
PESD5V0X1BCL-Q | Extremely low capacitance bidirectional ESD protection diode | Production | |
PESD5Z3.3-Q | Low capacitance unidirectional ESD protection diode | Production | |
PTVS8V0P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD5V0U2BM-Q | Ultra low capacitance bidirectional double ESD protection array | Production | |
PESD1IVN24LS-Q | ESD protection for in-vehicle networks | Production | |
PESD2CANFD36LQC-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD32VF1BLS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
PESD5V0S2BT-Q | Low capacitance bidirectional double ESD protection diode | Production | |
PESD5V0L1UB-Q | Low capacitance unidirectional ESD protection diodes | Production | |
PESD36VS1UJ-Q | Unidirectional ESD protection diode | Production | |
PESD5V2S2UT-Q | Double ESD protection diode | Production | |
PESD5V0U1BL-Q | Low capacitance bidirectional ESD protection diode | Production | |
PESD8V0S1ULD-Q | Unidirectional ESD protection diode | Production | |
PESD2ETHD-Q | Ultra low capacitance double rail-to-rail ESD protection diode | Production | |
PESD5V0S1UL-Q | Unidirectional ESD protection diode | Production | |
PESD5V0V2BMB-Q | Very low capacitance bidirectional ESD protection diodes | Production | |
PESD5V0S2BQA-Q | Protection against high surge currents in ultra small DFN1010D-3 package | Production | |
PESD15VS5UD-Q | Fivefold ESD protection diode array | Production | |
PESD3V3S2UT-Q | Double ESD protection diode | Production | |
PESD12VL1BA-Q | Low capacitance bidirectional ESD protection diode | Production | |
PESD15VL1BA-Q | Low capacitance bidirectional ESD protection diode | Production | |
PTVS13VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS3V3P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS64VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS16VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS7V5S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS20VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS30VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD18VF1BLS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
PTVS54VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD5V0L1UA-Q | Low capacitance unidirectional ESD protection diode | Production | |
PTVS3V3S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS48VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PESD3V3L1BA-Q | Low capacitance bidirectional ESD protection diode | Production | |
PRTR5V0U2AX-Q | Ultra low capacitance double rail-to-rail ESD protection diode | Production | |
PTVS10VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS3V3S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS7V0S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS20VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS26VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS11VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS12VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS43VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS6V0P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS8V0S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS48VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS5V0S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS9V0P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
MMBZ27VCT-Q | Double ESD protection diode | Production | |
PTVS6V5S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS8V5P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS8V5S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
MMBZ20VCL-Q | Double ESD protection diode for transient overvoltage suppression | Production | |
PTVS9V0S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PESD3V3S5UD-Q | Fivefold ESD protection diode array | Production | |
PESD15VU1UT-Q | Ultra low capacitance ESD protection diode | Production | |
PESD2CANFD36UQB-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD5V0S1BL-Q | Low capacitance bidirectional ESD protection diode | Production | |
PESD1IVN27L-Q | Bidirectional ESD protection diode | Production | |
PESD24VS1ULD-Q | Unidirectional ESD protection diode | Production | |
PESD5V0X1BL-Q | Ultra low capacitance bidirectional ESD protection diode | Production | |
PESD18VF1BALS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
PESD2CANFD36LQB-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
MMBZ18VCL-Q | Double ESD protection diode for transient overvoltage suppression | Production | |
PESD3V3S1UL-Q | Unidirectional ESD protection diode | Production | |
PTVS4V5D1BL-Q | Ultra compact Transient Voltage Supressor | Production | |
PESD24VS1UL-Q | Unidirectional ESD protection diode | Production | |
PESD1IVN27U-Q | ESD protection for in-vehicle networks | Production | |
PESD5V0L2UU-Q | Low capacitance unidirectional ESD protection diode | Production | |
PESD2CANFD36UQC-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD2CANFD24LU-Q | ESD protection for in-vehicle networks | Production | |
PESD24VS5UD-Q | Fivefold ESD protection diode array | Production | |
PESD12VS5UD-Q | Fivefold ESD protection diode array | Production | |
PESD5V0X2UMB-Q | Ultra low capacitance unidirectional double ESD protection diode | Production | |
PESD15VS1ULD-Q | Unidirectional ESD protection diode | Production | |
PESD5Z5.0-Q | Low capacitance unidirectional ESD protection diode | Production | |
PESD5V0U1UT-Q | Ultra low capacitance ESD protection diode | Production | |
PESD27VV2BT-Q | Bidirectional double ESD protection diode | Production | |
PESD24VF1BALS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
MMBZ18VAT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PESD3V3T1BL-Q | Bidirectional ESD protection diode | Production | |
PESD2CANFD36VQC-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
PESD3V3T1BLD-Q | Bidirectional ESD protection diode | Production | |
PESD12VS1UB-Q | ESD protection diode | Production | |
PESD5V0L2UMB-Q | Low capacitance unidirectional double ESD protection array | Production | |
PESD2CANFD27LT-Q | ESD protection for in-vehicle networks | Production | |
PESD32VF1BALS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
PESD30VF1BALS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
PESD5V0X1BCAL-Q | Extremely low capacitance bidirectional ESD protection diode | Production | |
PESD2ETHX-Q | Ultra low capacitance double rail-to-rail ESD protection diode | Production | |
PESD24VS2UT-Q | Double ESD protection diode | Production | |
PESD3V3S1UB-Q | ESD protection diode in SOD523 package | Production | |
PESD24VS1UA-Q | Unidirectional ESD protection diode | Production | |
PESD12VS1UA-Q | Unidirectional ESD protection for transient voltage suppression | Production | |
PESD5V0S1UB-Q | ESD protection diode | Production | |
PTVS24VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD5V0U1BLD-Q | Ultra low capacitance bidirectional ESD protection diode | Production | |
PTVS30VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS60VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS58VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS24VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD30VF1BLS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
PTVS45VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD5V0V1BL-Q | Very low capacitance bidirectional ESD protection diode | Production | |
PESD5V0S1BB-Q | Bidirectional ESD protection diode | Production | |
PTVS17VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS28VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS33VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS13VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS12VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS6V5P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS10VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PESD24VF1BLS-Q | Ultra-low capacitance bidirectional ESD protection diode | Production | |
PTVS7V5P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS7V5S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PESD3V3S2UAT-Q | Double ESD protection diode in SOT23 package | Production | |
MMBZ16VAL-Q | High surge current unidirectional double ESD protection diode | Production | |
PESD1IVN24A-Q | ESD protection for in-vehicle networks | Production | |
PESD2ETH1GT-Q | ESD protection for in-vehicle networks | Production | |
PESD5V0X1UALD-Q | Ultra low capacitance unidirectional ESD protection diode | Production | |
PESD5V0U2BMB-Q | Ultra low capacitance bidirectional double ESD protection array | Production | |
PESD12VV1BL-Q | Very low capacitance bidirectional ESD protection diode | Production | |
PESD42VS2UT-Q | Double ESD protection diode array | Production | |
PESD24VV2BT-Q | Bidirectional double ESD protection diode | Production | |
PTVS13VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS51VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS36VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS64VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS10VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS3V3P1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS22VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS60VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS40VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS16VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS12VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS6V5S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS24VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS26VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS36VS1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
PTVS18VP1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS48VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS43VS1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS5V0P1UTP-Q | High-temperature 600 W Transient Voltage Suppressor | Production | |
PTVS5V0P1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS26VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS33VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS40VP1UP-Q | 600 W Transient Voltage Suppressor | Production | |
PTVS7V0S1UR-Q | 400 W Transient Voltage Suppressor | Production | |
PTVS8V0S1UTR-Q | High-temperature 400 W Transient Voltage Suppressor | Production | |
MMBZ27VCL-Q | Double ESD protection diode for transient overvoltage suppression | Production | |
MMBZ6V8AL | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ9V1AL | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ33VAL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ6V2AL | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ5V6AL | Low capacitance unidirectional double ESD protection diode | Production | |
PESD3V3U1UB | Ultra low capacitance unidirectional ESD protection diodes | Production | |
PESD2ETH-AD | Ultra low capacitance double rail-to-rail ESD protection diode | Production | |
PESD30VF1BL | Bidirectional ESD protection diode | NotForDesignIn | |
PESD3V3U1UA | Ultra low capacitance unidirectional ESD protection diodes | Production | |
MMBZ15VAL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ16VAT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PESD5V0U1BA-Q | Low capacitance bidirectional ESD protection diode | Production | |
MMBZ10VAL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PESD24VF1BL-Q | Ultra low capacitance bidirectional ESD protection diode | Production | |
MMBZ20VAT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ12VAT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ12VAL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ27VAL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PESD5V5C1UL-Q | Extremely low clamping unidirectional ESD protection diode | Production | |
PESD5V5C1BL-Q | Extremely low clamping bidirectional ESD protection diode | Production | |
MMBZ6V2AL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PESD2ETHAD-Q | Ultra low capacitance double rail-to-rail ESD protection diode | Production | |
MMBZ18VAL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ20VAL-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ6V2AT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ5V6AT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ10VAT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ6V8AT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
PESD5V0F1BRLD-Q | Femtofarad bidirectional ESD protection diode | Production | |
PESD18VF1BBL-Q | Bidirectional ESD protection diode | Production | |
PESD24VF1BBL-Q | Bidirectional ESD protection diode | Production | |
PESD18VF1BL-Q | Ultra low capacitance bidirectional ESD protection diode | Production | |
PESD5V0F1BLD-Q | Femtofarad bidirectional ESD protection diode | Production | |
PRTR5V0U4D-Q | Ultra low capacitance quadruple rail-to-rail ESD protection | Production | |
PESD5V0V1BLD-Q | Very low capacitance bidirectional ESD protection diode | Production | |
PESD5V0S1BLD-Q | Bidirectional ESD protection diode | Production | |
PESD30VF1BBL-Q | Bidirectional ESD protection diode | Production | |
MMBZ33VAT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ9V1AT-Q | Low capacitance unidirectional double ESD protection diode | Production | |
MMBZ27VUA-Q | TVS device for surge protection of interface and supply lines | Production | |
MMBZ27VAT-Q | TVS device for surge protection of interface and supply lines | Production |
Brochure (2) |
|||
---|---|---|---|
文件名称 | 标题 | 类型 | 日期 |
Nexperia_ESD_Automotive_Application_Guide.pdf | ESD Automotive Application Guide | Brochure | 2023-02-16 |
Nexperia_document_brochure_application-guide_automotive.pdf | Nexperia Application Guide Automotive | Brochure | 2019-05-31 |
Leaflet (4) |
|||
文件名称 | 标题 | 类型 | 日期 |
ESD-Protection-for-automotive-infotainment-and-SerDes.pdf | ESD Protection for automotive infotainment and SerDes | Leaflet | 2021-04-19 |
Nexperia_ESD_Protection_for_automotive_CAN-FD.pdf | ESD Protection for automotive CAN-FD | Leaflet | 2020-11-27 |
Nexperia_ESD_Protection_for_automotive_infotainment_and_SerDes_CN.pdf | ESD Protection for automotive infotainment and SerDes CN | Leaflet | 2020-07-15 |
Nexperia_Automotive_Ethernet_ESD_Protection_Factsheet_CN.pdf | 汽车以太网ESD保护 | Leaflet | 2020-02-12 |
Marcom graphics (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
SOT457_mk.png | plastic, surface-mounted package (SC-74) | Marcom graphics | 2018-11-26 |
Selection guide (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
Nexperia_Selection_guide_2023.pdf | Nexperia Selection Guide 2023 | Selection guide | 2023-05-10 |
White paper (6) |
|||
文件名称 | 标题 | 类型 | 日期 |
Nexperia_White_paper_Using_ESD_Protection_Device_as_a_3D_Model_in_Simulations_082024.pdf | ESD protection devices in 3D Model Simulations. | White paper | 2024-05-31 |
Nexperia_Whitepaper_ESD_Protection_for_Automotive_GER.pdf | ESD-Schutz für High-Speed-Video-Links im Automobil | White paper | 2021-11-16 |
Nexperia_Whitepaper_ESD_Protection_for_Automotive_High-Speed_Video_Links_CN.pdf | 汽车高速视频链路的ESD保护 | White paper | 2021-08-06 |
Nexperia_Whitepaper_ESD_Protection_for_Automotive_High-Speed_Video_Links.pdf | ESD Protection for Automotive High-Speed Video Links | White paper | 2021-07-13 |
Nexperia_Whitepaper_ESD_Discharge_Current_Measurement_Using_SEED_CN.pdf | 运用SEED设计方法,根据开放技术联盟100BASE-T1规范 | White paper | 2020-02-26 |
Nexperia_Whitepaper_ESD_Discharge_Current_Measurement_Using_SEED_1.pdf | Efficient prediction of ESD discharge current according to OPEN Alliance 100BASE-T1 specification using SEED | White paper | 2019-12-19 |
常见问题
传输线脉冲(TLP)是50 Ω受控阻抗环境中的短时矩形脉冲,可提高测试准确度和测量再现性。
TLP能够表征具有短脉冲宽度和快上升时间的受力设备的性能特性。每个测量结果都成为TLP图上的一个点,显示TLP I-V特性,即构成TLP曲线。
Nexperia的汽车级产品符合AEC-Q101标准(如果在数据手册中注明)。由于未通电,ESD器件显示出非常低的自发热特性。此外,Nexperia根据JEDEC和ISO规范进行了多项可靠性测试,以确保高可靠性。
基本上,ESD故障有两种模式:器件损坏的破坏性故障和表现为软故障的非破坏性故障。非破坏性故障很难检测,但有助于在递增的更高电压下进行测试,以确定破坏性故障点。这样,有时可以及早检测到器件的老化,从而给出潜在风险的第一个指示。泄漏电流的偏差也会给出很好的指示。
对于24 V直流电源线,由于快速启动的要求,需要最小32 V的反向关态电压
SEED(高效的系统级ESD设计)仿真是仿真ESD事件的一种有效方法。它特别有助于将IC与分立ESD保护匹配起来。关于进一步介绍,我们推荐您阅读我们的白皮书,其中说明了概念和基本步骤
从一般的ESD设计方面来看,ESD设计策略是独立的。但是,附加要求可能会缩小适用保护器件的范围,并包括进一步的测试。例如,ISO10605规定了针对汽车应用的附加测试。
Nexperia的汽车级产品符合AEC-Q101标准(如果在数据手册中注明)。我们所有的产品都被视为基础构建模块,其中功能安全的关键性由系统定义。这一点很重要,因为一个器件/系统的默认故障模式可能不适用于另一个器件/系统,这也是我们无法根据ISO26262方法假定任何ASIL评级的原因。Nexperia可为将在安全关键应用中使用ESD保护器件的客户提供更多详细信息和支持。
根据应用和保护器件的不同,散射参数可以包含在数据手册中。可按需通过电子邮件发送散射参数数据。
对于sub GHz应用,ESD保护器件的电容对阻抗有重要影响。为了改善阻抗曲线,可以用较低电容的器件来提高性能。封装在这方面影响较小。
串扰取决于子系统。随着PCB设计变得越来越小,并显示出越来越高的走线密度,可能存在更高的串扰风险。但是,这更多的是在PCB表面,而不是外围。
如果只使用一个电容,ESD脉冲可能会衰减一点,但系统级保护非常低。分立ESD保护器件显著提高了系统级ESD的稳健性,并增强了系统的可靠性。
连接器上的传导放电仅受您所设计的模块外壳的轻微影响。空气放电很大程度上取决于外壳,因此,在开发过程中应予以考虑。
有关DFN封装焊接和AOI指南,请参阅Nexperia应用说明。
在这个例子中,PCB有4层或更多层,GND层正好位于顶层下方,预浸料约为100 μm。因此100 μm的通孔电感很小。但是,您可以根据PCB堆叠规划不同的GND引脚布线。
同轴电缆(单端)或差分传输对ESD保护器件的电气性能没有实际影响。这可能会影响保护器件的封装,因为您需要确定必须保护的线路数量。
我们目前正在为除USBx和HDMIx之外的其他应用进行眼图测量和仿真。
通过TLP曲线比较可以快速看出这一点。因此,ESD保护器件应在PHY的内部ESD保护之前触发。例如,如果ESD保护的击穿电压为35 V,PHY的击穿电压为60 V,则是很好的匹配。在这一组合中,ESD保护会首先钳位并吸收绝大部分ESD脉冲。
可能存在一些与DPI测试有关的问题。在测试过程中,网络吸收了过多能量时就会出现。在这种情况下,您需要选择触发电压更高的ESD保护器件。
走线应直接布线至ESD保护器件,而不需要更改层或耦合至其他PCB结构。但是,布线在很大程度上取决于子应用,因此无法包含在数据手册中。
所有的Nexperia封装均符合AEC-Q101和其他最高质量标准。
原因是在DPI测试期间,RF噪声可达到高达100 V的振幅。为避免ESD保护器件钳位,触发电压规定为大于100 V。超过24 V的直流电压与对电池短路的要求有关(与CAN/LIN类似)。
对于LIN/CAN/以太网等一些应用,3引脚封装不会对信号完整性产生显著影响。对于SerDes和Multimedia等高频应用,我们建议使用其他封装,如无引脚封装。
对于1000BASE-T1,PESD2ETH1G-T可以以更小的寄生电容(小于2 pF)使用。有关更多产品信息,请参阅网页上的选型手册。
通过眼图,您可以判断ESD保护是否对您的数字系统影响过大。除了散射参数和寄生电容之外,这是另一种看待设备级信号完整性的角度。
对于CAN,更重要的是电容。但是,对于某些CAN产品,Nexperia还是会为其提供散射参数。
有关更多产品信息,请访问我们的网页
