Key features and benefits
- 1 mm package height for thin PCB designs
- Up to 60% footprint savings - CFP compared to SMx
- High current pulse capability due to solid copper clip-bond
- High efficiency planar technology / High power density
- Low magnetic inductance optimizes switching behavior
- 200 V hyper-fast switching parts with optimized recovery time (trr) of < 20 ns
- High speed switching capability
- Low voltage drop (VF @ IF(max) ~ 1 V)
- Low leakage current, also at high temperature
- AEC-Q101 qualified parts (175 °C Tj (max))
Key applications
- Polarity protection
- DC/DC conversion
- AC/DC conversion
- Freewheeling of inductive load
- Standard switching applications
- High-speed switching applications
- Engine and Transmission Control Unit
- Solenoid control
- Piezo injection
Latest news and blogs
Latest videos
参数搜索
Recovery rectifiers
数据加载中,请稍候...
参数搜索不可用。
产品
型号 | 描述 | 状态 | 快速访问 |
---|---|---|---|
ES2DP | 200 V, 2 A hyperfast PN-rectifier | EndOfLife | |
ES3DP | 200 V, 3 A hyperfast PN-rectifier | EndOfLife | |
ES1DVR | 200 V, 1 A hyperfast PN-rectifier | EndOfLife | |
ES1DR | 200 V, 1 A hyperfast PN-rectifier | EndOfLife | |
ES1GR | 400 V, 1 A hyperfast switching time PN-rectifier | EndOfLife | |
ES2DVR | 200 V, 2 A hyperfast PN-rectifier | EndOfLife | |
ES2DR | 200 V, 2 A hyperfast PN-rectifier | EndOfLife | |
PNE200100CPE | 200 V, 2 x 5 A dual common cathode hyperfast recovery rectifier | Production | |
PNU65030EP | 650 V, 3 A ultrafast recovery rectifier | Production | |
PNE20050EP | 200 V, 5 A hyperfast recovery rectifier | Production | |
PNE20020ER | 200 V, 2 A hyperfast recovery rectifier | Production | |
PNE20010ER | 200 V, 1 A hyperfast recovery rectifier | Production | |
PNE20040CPE | 200 V, 2 x 2 A dual common cathode hyperfast recovery rectifier | Production | |
PNE20080CPE | 200 V, 2 x 4 A dual common cathode hyperfast recovery rectifier | Production | |
PNU65010EP | 650 V, 1 A ultrafast recovery rectifier | Production | |
PNE20040EP | 200 V, 4 A hyperfast switching recovery rectifier | Production | |
PNE20010EXD | 200 V, 1 A hyperfast recovery rectifier | Production | |
PNE20020EP | 200 V, 2 A hyperfast recovery rectifier | Production | |
PNU65010ER | 650 V, 1 A ultrafast recovery rectifier | Production | |
PNU65020EP | 650 V, 2 A ultrafast recovery rectifier | Production | |
PNE20060EPE | 200 V, 6 A hyperfast recovery rectifier | Production | |
PNE20030EP | 200 V, 3 A hyperfast recovery rectifier | Production | |
S1DR | 200 V, 1 A high power density, standard switching time PN-rectifier | EndOfLife | |
PNE20060CPE | 200 V, 2 x 3 A dual common cathode hyperfast recovery rectifier | Production | |
PNE200100EPE | 200 V, 10 A hyperfast recovery rectifier | Production | |
PNE20040EPE | 200 V, 4 A hyperfast recovery rectifier | Production | |
PNE20080EPE | 200 V, 8 A hyperfast recovery rectifier | Production | |
PNE20020AER | 200 V, 2 A hyperfast recovery rectifier | Production | |
PNE650200EJ | 650 V, 20 A hyperfast recovery rectifier | Production | |
PNU650100EJ | 650 V, 10 A ultrafast recovery rectifier | Production | |
PNS40010AER | 400 V, 1 A high power density, standard switching time recovery rectifier | Production | |
PNU650150EJ | 650 V, 15 A ultrafast recovery rectifier | Production | |
PNU650200AEJ | 650 V, 20 A ultrafast recovery rectifier | Production | |
PNE650100EJ | 650 V, 10 A hyperfast recovery rectifier | Production | |
PNE650150EJ | 650 V, 15 A hyperfast recovery rectifier | Production | |
PNU650200EJ | 650 V, 20 A ultrafast recovery rectifier | Production | |
PNU650300AEJ | 650 V, 30 A ultrafast recovery rectifier | Production | |
PNE20020EXD | 200 V, 2 A hyperfast recovery rectifier | Production | |
PNU650150AEJ | 650 V, 15 A ultrafast recovery rectifier | Production | |
PNS40010ER | 400 V, 1 A high power density, standard switching time recovery rectifier | EndOfLife | |
PNE20060EPE-Q | 200 V, 6 A hyperfast recovery rectifier | Production | |
PNE200100CPE-Q | 200 V, 2 x 5 A dual common cathode hyperfast recovery rectifier | Production | |
PNE20040CPE-Q | 200 V, 2 x 2 A dual common cathode hyperfast recovery rectifier | Production | |
PNE20040EPE-Q | 200 V, 4 A hyperfast recovery rectifier | Production | |
PNE20060CPE-Q | 200 V, 2 x 3 A dual common cathode hyperfast recovery rectifier | Production | |
PNE20080EPE-Q | 200 V, 8 A hyperfast recovery rectifier | Production | |
PNE200100EPE-Q | 200 V, 10 A hyperfast recovery rectifier | Production | |
PNU65010ER-Q | 650 V, 1 A ultrafast recovery rectifier | Production | |
PNU65030EP-Q | 650 V, 3 A ultrafast recovery rectifier | Production | |
PNE20010EXD-Q | 200 V, 1 A hyperfast recovery rectifier | Production | |
PNE20050EP-Q | 200 V, 5 A hyperfast recovery rectifier | Production | |
PNE20030EP-Q | 200 V, 3 A hyperfast recovery rectifier | Production | |
PNE20020EP-Q | 200 V, 2 A hyperfast recovery rectifier | Production | |
PNU650150AEJ-Q | 650 V, 15 A ultrafast recovery rectifier | Production | |
PNU65020EP-Q | 650 V, 2 A ultrafast recovery rectifier | Production | |
PNU650300AEJ-Q | 650 V, 30 A ultrafast recovery rectifier | Production | |
PNE20020AER-Q | 200 V, 2 A hyperfast recovery rectifier | Production | |
PNE20020ER-Q | 200 V, 2 A hyperfast recovery rectifier | Production | |
PNU65010EP-Q | 650 V, 1 A ultrafast recovery rectifier | Production | |
PNE20010ER-Q | 200 V, 1 A hyperfast recovery rectifier | Production | |
PNE20040EP-Q | 200 V, 4 A hyperfast switching recovery rectifier | Production | |
PNU650150EJ-Q | 650 V, 15 A ultrafast recovery rectifier | Production | |
PNE650150EJ-Q | 650 V, 15 A hyperfast recovery rectifier | Production | |
PNE20080CPE-Q | 200 V, 2 x 4 A dual common cathode hyperfast recovery rectifier | Production | |
PNE650100EJ-Q | 650 V, 10 A hyperfast recovery rectifier | Production | |
PNU650100EJ-Q | 650 V, 10 A ultrafast recovery rectifier | Production | |
PNS40010AER-Q | 400 V, 1 A high power density, standard switching time recovery rectifier | Production | |
PNU650200EJ-Q | 650 V, 20 A ultrafast recovery rectifier | Production | |
PNE650200EJ-Q | 650 V, 20 A hyperfast recovery rectifier | Production | |
PNU650200AEJ-Q | 650 V, 20 A ultrafast recovery rectifier | Production | |
PNE20020EXD-Q | 200 V, 2 A hyperfast recovery rectifier | Production |
Visit our documentation center for all documentation
Brochure (2) |
|||
---|---|---|---|
文件名称 | 标题 | 类型 | 日期 |
Nexperia_document_brochure_Recovery_rectifier.pdf | Hyperfast recovery, space-saving devices | Brochure | 2024-05-08 |
Nexperia_document_brochure_Recovery_rectifier_CN_2022.pdf | 恢复整流器 | Brochure | 2023-03-29 |
Data sheet (4) |
|||
文件名称 | 标题 | 类型 | 日期 |
PNU65010EP-Q.pdf | 650 V, 1 A ultrafast recovery rectifier | Data sheet | 2022-10-18 |
PNU65010ER.pdf | 650 V, 1 A ultrafast recovery rectifier | Data sheet | 2022-09-30 |
PNU65010ER-Q.pdf | 650 V, 1 A ultrafast recovery rectifier | Data sheet | 2022-09-30 |
PNU65010EP.pdf | 650 V, 1 A ultrafast recovery rectifier | Data sheet | 2022-09-30 |
Leaflet (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
NEX_173_Leaflet-PackageStrategy_update_v01_2023.pdf | NEX_173_Leaflet - Package Strategy update v01 (2) | Leaflet | 2023-11-22 |
Marcom graphics (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
CFP3_SOD123W_mk.png | plastic, surface mounted package; 2 terminals; 2.6 mm x 1.7 mm x 1 mm body | Marcom graphics | 2017-01-28 |
Selection guide (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
Nexperia_Selection_guide_2023.pdf | Nexperia Selection Guide 2023 | Selection guide | 2023-05-10 |
