主要特性和优势
- ± 10%电阻比容差
- 降低贴片成本
- 内置偏置电阻
- 减少器件数量
- 100 mA、500 mA和最高600 mA的输出电流能力
- 简化电路设计
关键应用
- 控制IC输入
- 数字系统
- 开关负载
Latest videos
参数搜索
产品
型号 | 描述 | 状态 | 快速访问 |
---|---|---|---|
PDTA113E series | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | ACT |
|
PDTA113EM | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PDTA113ET | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PDTA113EU | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PDTA113Z series | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm | ACT |
|
PDTA113ZM | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PDTA113ZT | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PDTA113ZU | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PDTA114T series | PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | ACT |
|
PDTA114TM | PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTA114TT | PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTA114TU | PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTA114Y series | PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | ACT |
|
PDTA114YM | PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA114YT | PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA114YU | PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA115E series | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm | ACT |
|
PDTA115EM | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA115EMB | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA115ET | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA115EU | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA115EU-Q | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA115T series | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open | ACT |
|
PDTA115TM | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTA115TT | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTA115TU | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTA123E series | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 2.2 kOhm | ACT |
|
PDTA123EM | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA123EMB | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA123ET | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA123EU | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA123EU-Q | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA123J series | PNP resistor-equipped transistors; R1 = 2.2 kΩ, R2 = 47 kΩ | ACT |
|
PDTA123JM | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA123JT | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA123JU | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA123T series | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | ACT |
|
PDTA123TM | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTA123TT | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTA123TU | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTA123Y series | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | ACT |
|
PDTA123YM | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | Production | |
PDTA123YT | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | Production | |
PDTA123YU | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | Production | |
PDTA124E-[369] | PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | ACT |
|
PDTA124EM | PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTA124ET | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTA124EU | PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTA124T series | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | ACT |
|
PDTA124TM | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTA124TT | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTA124TU | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTA124X series | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | ACT |
|
PDTA124XM | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA124XT | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA124XU | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA143/114/124/144EQA series | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA124EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143E series | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | ACT |
|
PDTA143EM | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTA143ET | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTA143EU | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTA143T series | PNP resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open | ACT |
|
PDTA143TM | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTA143TT | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTA143X series-[369] | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | ACT |
|
PDTA143XM | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTA143XT | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTA143XU | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTA143X/123J/143Z/114YQA series | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114YQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA123JQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143XQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143ZQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143X_TO_124XQB series-[369] | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114YQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA123JQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA124XQB | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143XQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143ZQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143X_TO_124XQC Series-[369] | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114YQC | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA123JQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA124XQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143XQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143ZQC | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143X_TO_124XQC-Q Series | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114YQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA123JQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA124XQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143XQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143ZQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143Z series | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | ACT |
|
PDTA143ZM | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA143ZMB | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA143ZQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143ZQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143ZQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143ZQC | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143ZQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143ZT | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA143ZT-Q | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA143ZU | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA143_114_124_144EQB series | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA124EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA144EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143_114_124_144EQC Series | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114EQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA124EQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143EQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144EQC | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143_114_124_144EQC-Q Series | 50 V, 100 mA PNP resistor-equipped transistors | ACT |
|
PDTA114EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA124EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144E series | PNP resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ | ACT |
|
PDTA144EM | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTA144ET | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTA144EU | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTA144T series | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | ACT |
|
PDTA144TM | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTA144TT | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTA144TU | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTA144V series | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | ACT |
|
PDTA144VM | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTA144VT | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTA144VU | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTA144W series | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | ACT |
|
PDTA144WM | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTA144WT | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTA144WU | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTB113Z_123Y_143XQA_SER | 50 V, 500 mA PNP resistor-equipped transistors | ACT |
|
PDTB113ZQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTB123YQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTB143XQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTB113_123_143_114EQA_SER | 50 V, 500 mA PNP resistor-equipped transistors | ACT |
|
PDTB113EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTB114EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTB123EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTB143EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTB1xxxT series | 500 mA, 50 V PNP resistor-equipped transistors | ACT |
|
PDTB114ET | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB143ET | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB143XT | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB1xxxU series | 500 mA, 50 V PNP resistor-equipped transistors | ACT |
|
PDTB113EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB113ZU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB114EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB114EU-Q | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB123EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB123YU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB143EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB143XU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTC114T series | NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open | ACT |
|
PDTC114TM | NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTC114TT | NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTC114TU | NPN resistor-equipped transistor; R1 = 10 kOhm, R2 = open | Production | |
PDTC115E series | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm | ACT |
|
PDTC115EM | 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC115ET | 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC115EU | 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC115T series-[369] | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open | ACT |
|
PDTC115TM | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTC115TT | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTC115TU | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTC123E series | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 2.2 kOhm | ACT |
|
PDTC123EM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTC123ET | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTC123EU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTC123T series | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | ACT |
|
PDTC123TM | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTC123TT | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTC123TU | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTC123Y series | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | ACT |
|
PDTC123YM | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC123YU | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC124T series | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open | ACT |
|
PDTC124TM | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTC124TT | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTC124TU | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTC124X series | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | ACT |
|
PDTC124XM | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PDTC124XT | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PDTC124XU | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PDTC143/114/124/144EQA series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC144EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143T series | NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open | ACT |
|
PDTC143TM | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC143TT | NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC143TU | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC143X/123J/143Z/114YQA series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114YQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC123JQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143XQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143ZQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143X_TO_124XQB Series-[369] | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114YQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC123JQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC124XQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143XQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143ZQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143X_TO_124XQB-Q Series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114YQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC123JQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124XQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143XQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143ZQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143X_TO_124XQC Series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114YQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC123JQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC124XQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143XQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143ZQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143X_TO_124XQC-Q Series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114YQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC123JQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124XQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143XQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143ZQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143_114_124_144EQB Series-[369] | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114EQB | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124EQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143EQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC144EQB | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143_114_124_144EQB-Q Series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC144EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143_114_124_144EQC Series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114EQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC124EQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143EQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC144EQC | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143_114_124_144EQC-Q Series | 50 V, 100 mA NPN resistor-equipped transistors | ACT |
|
PDTC114EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC144EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC144T series | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open | ACT |
|
PDTC144TM | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC144TT | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC144TU | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC144V series | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | ACT |
|
PDTC144VM | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTC144VT | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTC144VU | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTC144W series | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | ACT |
|
PDTC144WM | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTC144WT | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTC144WU | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTD123Y series | NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | ACT |
|
PDTD123YQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PDTD123YT | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTD123YT-Q | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTD123YU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD1xxxT series-[369] | 500 mA, 50 V NPN resistor-equipped transistors | ACT |
|
PDTD114ET | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTD143ET | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTD143ET-Q | 500 mA, 50 V NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTD143XT | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTD1xxxU series-[369] | 500 mA, 50 V NPN resistor-equipped transistors | ACT |
|
PDTD113EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD113ZU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD114EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD114EU-Q | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD123EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD123YU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD143EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD143XU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PEMB13; PUMB13 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | ACT |
|
PEMB13 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PEMB14; PUMB14 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | ACT |
|
PUMB14 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PEMB15; PUMB15 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | ACT |
|
PUMB15 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PEMB16; PUMB16 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | ACT |
|
PUMB16 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PEMB17; PUMB17 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | ACT |
|
PEMB17 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | EndOfLife | |
PUMB17 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PEMB18; PUMB18 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | ACT |
|
PEMB18 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | EndOfLife | |
PUMB18 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PEMB19; PUMB19 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | ACT |
|
PEMB19 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | EndOfLife | |
PUMB19 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PEMB1; PUMB1 | PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | ACT |
|
PEMB1 | PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | EndOfLife | |
PUMB1 | PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PEMB30; PUMB30 | PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | ACT |
|
PEMB30 | PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | EndOfLife | |
PUMB30 | PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PEMB4; PUMB4 | PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | ACT |
|
PEMB4 | PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | EndOfLife | |
PUMB4 | PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PEMD12; PUMD12 | NPN/PNP resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ | ACT |
|
PUMD12 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PEMD17; PUMD17 | NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | ACT |
|
PEMD17 | NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | EndOfLife | |
PUMD17 | NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PEMD18; PUMD18 | NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | ACT |
|
PEMD18 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | EndOfLife | |
PEMD19; PUMD19 | NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | ACT |
|
PEMD19 | NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | EndOfLife | |
PUMD19 | NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PEMH17; PUMH17 | NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | ACT |
|
PEMH17 | NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | EndOfLife | |
PUMH17 | NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PEMH24; PUMH24 | NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm | ACT |
|
PEMH24 | NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm | EndOfLife | |
PUMH24 | NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm | Production | |
PEMH30; PUMH30 | NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | ACT |
|
PEMH30 | NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | EndOfLife | |
PUMH30 | NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PEMH7; PUMH7 | NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open | ACT |
|
PEMH7 | NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open | EndOfLife | |
PUMH7 | NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open | Production | |
PEMH9; PIMH9; PUMH9 | NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | ACT |
|
PEMH9 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PIMH9 | NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMH9 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMH9-Q | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
NHUMH1 | 80 V, 100 mA NPN/NPN resistor-equipped double transistors | Production | |
NHDTA124ET | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTC124ET | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTA123JT | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTC144EU | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
PBRN113ES | EndOfLife | ||
PBRP113ZT | 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PBRP123ET | 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA144WT | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTB123YT | 50 V, 500 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
NHDTC114ET | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHUMH2 | 80 V, 100 mA NPN/NPN resistor-equipped double transistors | Production | |
NHUMH11 | 80 V, 100 mA NPN/NPN resistor-equipped double transistors | Production | |
NHDTA144ET | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTC144ET | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
PBRN113EK | EndOfLife | ||
PBRP123YT | 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA143ZT | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA123EU | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA114EQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA123YT | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | Production | |
PBRN123ET | 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PEMD4 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = open | Production | |
PEMB30 | PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | EndOfLife | |
PEMB3 | 50 V, 100 mA PNP/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PEMD17 | NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | EndOfLife | |
PDTC144EU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PIMD3 | NPN/PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PEMB24 | 50 V, 20 mA PNP/PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PEMB18 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | EndOfLife | |
PBRN113ET | 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 1 kΩ | Production | |
PDTC114TM | NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTC144ET | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTC114YT | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTC143ZQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA143ET | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTD113ET | NPN 500 mA, 50 V resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PEMH16 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA143XQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143XM | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTA143EU | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTA143XU | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTC123JQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PEMD12 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PEMD30 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = open | Production | |
PEMD2 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PEMD19 | NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | EndOfLife | |
PEMD3 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTA115EM | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PEMB13 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PEMD10 | NPN/PNP double Resistor-Equipped Transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PEMD6 | 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTA144WM | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PEMH17 | NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | EndOfLife | |
PEMB1 | PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | EndOfLife | |
PDTC123JQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PEMH19 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = open | Production | |
PEMD9 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTC114EM | NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTC114TU | NPN resistor-equipped transistor; R1 = 10 kOhm, R2 = open | Production | |
PDTA123YM | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | Production | |
PEMH24 | NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm | EndOfLife | |
PEMB2 | 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTA143ZQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC114EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTB113ET | PNP 500 mA, 50 V resistor-equipped transistor; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PEMH2 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTC114TT | NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTA144TM | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC114EU | NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTD113ZT | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PEMH18 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PEMD48 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ and R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTC114YQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PEMB10 | 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PEMH30 | NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | EndOfLife | |
PDTC114YU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PEMB19 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | EndOfLife | |
PEMD13 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PEMB11 | PNP/PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PEMD14 | 50 V, 100 mA NPN/PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = open | Production | |
PDTC144EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PEMH20 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PEMH4 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = open | Production | |
PEMF21 | 12 V PNP loadswitch | EndOfLife | |
PDTC143EQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PEMH7 | NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open | EndOfLife | |
PEMD20 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTC144EQC | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTD143XQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PDTD113EQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PEMB4 | PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | EndOfLife | |
PDTD123EQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PDTD143EQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PEMH15 | NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PBRN123YT | 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PEMH14 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open | Production | |
PDTD123YQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PDTD113ZQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PIMC31 | 500 mA, 50 V NPN/PNP double resistor-equipped transistor; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PEMH13 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
NHUMD12 | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
PDTA143ZU | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PEMB9 | 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PEMD24 | 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PBRN113ZT | 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PBRP113ET | 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 1 kΩ | Production | |
PEMH9 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PEMD18 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | EndOfLife | |
PDTA114YQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PEMB20 | 50 V, 100 mA PNP/PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PEMH1 | NPN/NPN resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PEMB17 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | EndOfLife | |
PEMH11 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PEMH10 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA143EQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA123YU | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm | Production | |
PDTA144EQC | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA144VT | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTA114EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
NHUMD3 | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHUMD2 | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
PDTA114YQC | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTC115TT | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTC114YM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA143ZQC | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTC123JT | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA115EU | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC143XQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA143TT | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC143ET | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTC143XQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA143EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA124TM | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTA143ZM | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA143TU | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTA144VM | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTC143ZQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124EQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PEMD15 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTA124EQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144WU | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTA123JQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTB123TT | PNP 500 mA, 50 V resistor-equipped transistor; R1 = 2.2 kOhm, R2 = open | Production | |
PDTC123YT | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC123JU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA124TU | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTA123TU | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTC124EQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC143EU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTD123YT | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA123JQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA143XT | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PEMD16 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTB113ZT | PNP 500 mA, 50 V resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PDTA144VU | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTA124TT | PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTA114EU | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTA123TM | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTA143XQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA114ET | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTA143EM | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTA124ET | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTC114YMB | NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA143TM | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC124EU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTC114EQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA144TT | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC114YQA | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTB123ET | PNP 500 mA, 50 V resistor-equipped transistor; R1 = 2.2 kOhm, R2 = 2.2 kOhm | Production | |
PDTA144TU | PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC123TT | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTC124ET | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTC143ZU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTD114EQA | 50 V, 500 mA NPN resistor-equipped transistors | Production | |
PQMH13 | NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PRMD16 | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) | Production | |
PUMB13 | PNP/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PUMD2 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PUMD4 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = open | Production | |
PIMH9 | NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMH1 | NPN/NPN resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PUMD10 | NPN/PNP double Resistor-Equipped Transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMH10 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMD3 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PUMD12 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PUMD24 | 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PUMD6H | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open | EndOfLife | |
PUMH11 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PUMD48 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ and R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMB2 | 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PUMD13 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PUMB11 | 50 V, 100 mA PNP/PNP resistor-equipped double transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PUMD15 | NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PUMD6 | 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PUMB3H | 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open | EndOfLife | |
PUMD9 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMH13 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1= 4.7 kΩ, R2 = 47 kΩ | Production | |
PUMH14 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open | Production | |
PUMH9 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMH15 | NPN/NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTC143ZQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC123JQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC144EQB | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124XQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA114EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA124XQB | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA123JQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA124EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA143EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTC114YQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTC124EQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA124XQC | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC143EQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA144EQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PIMC32 | 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PIMP32 | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC124XQC | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA143XQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTC143XQB | 50 V, 100 mA NPN resistor-equipped transistors | EndOfLife | |
PDTA143ZQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PUMH2 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PUMD16 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PIMN32 | 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PIMP31 | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PIMC31PA | 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PIMN31PA | 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PUMH7H | 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open | EndOfLife | |
PDTC114EQB | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA114YQB | 50 V, 100 mA PNP resistor-equipped transistors | EndOfLife | |
PDTA123YQB | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ | Production | |
PIMC32PA | 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PIMN32PA | 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC123YQB | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ | Production | |
PIMP31PA | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PIMP32PA | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA144ET | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTA124XM | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA144EM | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTA124XU | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA144EU | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTA124XT | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTC115EM | 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC114ET | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTB113ZU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB114EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB143ET | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTD114EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD143ET | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
NHDTA124EU | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHUMB9 | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHDTA123JU | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHUMD10 | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHUMB10 | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHDTC123JU | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTA143ZT | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHUMD9 | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHUMH9 | 80 V, 100 mA NPN/NPN resistor-equipped double transistor | Production | |
NHUMB11 | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHUMB2 | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHDTA114ET | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTA114EU | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA114YU | PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA124TMB | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = open | Production | |
NHDTA144EU | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA113ZMB | PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
NHDTC114YU | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHUMH13 | 80 V, 100 mA NPN/NPN resistor-equipped double transistor | Production | |
NHDTC143ZU | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTC114YT | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTC114EU | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTA114YT | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHUMB1 | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Qualification | |
NHDTC124EU | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTA143ZU | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHUMB13 | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHDTC143ZT | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHUMH10 | 80 V, 100 mA NPN/NPN resistor-equipped double transistor | Production | |
PDTA114YT | PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA123JU | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA123JT | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA114TM | PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTA123ET | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA124XMB | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA113EM | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PIMD2 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTC144TM | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC144TMB | NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open | Production | |
PDTB114EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTA143TMB | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC124XU | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PDTC143TM | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC143TMB | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTA144TMB | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = open | Production | |
PDTC144WM | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTB113ZQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTA114TT | PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTC114EMB | NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTD123ET | NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 2.2 kOhm | Production | |
PDTC114TMB | NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = open | Production | |
PDTC123TM | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTA114EMB | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTC124EM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTB113EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTA115TMB | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = open | Production | |
PDTA143ZMB | PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA123EMB | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA113ET | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PDTA114TU | PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PDTC143XT | NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTC124EMB | NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTA115TM | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTA144WMB | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ | Production | |
PDTB123EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTC143TT | NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC144TU | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC115TU | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTB123YQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTC124XMB | NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTC124XM | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PDTC144VM | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTC143XU | NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTC123EMB | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTC123YU | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC143XM | NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTC144EM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTC124TM | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTC124TMB | NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = open | Production | |
PDTC124TT | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTC143XMB | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTC144EMB | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTC143ZMB | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTC143ZM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTC144VU | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTC144VT | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm | Production | |
PDTC144WU | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTC144TT | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PDTC144WT | NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PDTA123JMB | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA114TMB | PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = open | Production | |
NHDTA114YU | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTC123JT | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA143EMB | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
NHUMD13 | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
PDTA113ZT | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PDTC123YMB | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA123YMB | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA113ZM | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PDTA123JM | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTC123YM | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA123EM | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTA124EMB | PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTA113EU | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm | Production | |
PDTC143TU | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC143ZT | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTC144VMB | NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 10 kΩ | Production | |
PDTA124EQA | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC124TU | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PDTC123JMB | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTA114EM | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTA144VMB | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 10 kΩ | Production | |
PDTA113ZU | PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PDTA115ET | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTB143XQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTC144WMB | NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ | Production | |
PDTC123JM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTC115EMB | NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA115TU | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTD123TT | NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTA124EM | PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTA114YMB | PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTA123TT | PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PDTA113EMB | PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 1 kΩ | Production | |
PDTA115TT | PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTA115EMB | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA124EU | PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTA123TMB | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = open | Production | |
PDTA143XMB | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTA144EMB | PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTB143EQA | 50 V, 500 mA PNP resistor-equipped transistors | Production | |
PDTC115TM | NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open | Production | |
PDTC143EM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTC123TMB | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = open | Production | |
PDTC115TMB | NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = open | Production | |
PDTC143EMB | NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTC124XT | NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PDTC123TU | NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PQMH11 | NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PQMD16 | NPN/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PRMD13 | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) | Production | |
PQMH2 | NPN/NPN resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PQMD2 | NPN/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PQMH9 | NPN/NPN resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PQMD13 | NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PUMD30 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = open | Production | |
PQMD12 | NPN/PNP resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PUMB14 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open | Production | |
PUMD20 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PUMH24 | NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm | Production | |
PQMB11 | PNP/PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PIMN31 | 500 mA, 50 V NPN/NPN double resistor-equipped transistor; R1 = 1 kOhm, R2 = 10 kOhm | Production | |
PUMB17 | PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PUMH4 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = open | Production | |
PUMH16 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PUMB18 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PQMD10 | NPN/PNP resistor-equipped transistors; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PQMD3 | NPN/PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PRMH13 | 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) | Production | |
PRMB11 | 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistors (RET) | Production | |
PRMD3 | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) | Production | |
PQMH10 | NPN/NPN resistor-equipped transistors; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PRMH2 | 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) | Production | |
PRMH10 | 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) | Production | |
PRMD2 | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) | Production | |
PUMH30 | NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PUMH19 | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = open | Production | |
PUMB9 | PNP/PNP double Resistor-Equipped Transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMH17 | NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PUMB1 | PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PUMB10 | 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMH18 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PRMH11 | 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) | Production | |
PRMH9 | 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) | Production | |
PUMB19 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PUMD14 | 50 V, 100 mA NPN/PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = open | Production | |
PUMB16 | PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm | Production | |
PUMB4 | PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open | Production | |
PUMD18 | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PUMD19 | NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open | Production | |
PUMB30 | PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open | Production | |
PUMB3 | 50 V, 100 mA PNP/PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PUMB15 | PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PUMH7 | NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open | Production | |
PBRP113ET-Q | 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 1 kΩ | Production | |
PBRN123ET-Q | 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PUMH7H-Q | 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PRMD10 | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) | Production | |
PUMD6H-Q | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PRMD12 | 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) | Production | |
PBRP123ET-Q | 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PBRP113ZT-Q | 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PDTB123YT-Q | 50 V, 500 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA143EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC114YQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA124XQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PUMH2-Q | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTC123JQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC114EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA143EQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC143XQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PUMD17 | NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm | Production | |
PUMF12 | PNP general purpose transistor; NPN resistor-equipped transistor | EndOfLife | |
PUMD10-Q | NPN/PNP double Resistor-Equipped Transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMD4-Q | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = open | Production | |
PDTA143XQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTD113ZT-Q | NPN 500 mA, 50 V resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PDTC123JQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC124XQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA114YQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA114EQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA114EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PUMH20 | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PUMB24 | 50 V, 20 mA PNP/PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTA143XQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTA144EQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC114EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA124EQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC124XQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PIMN32-Q | 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA123JQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PUMB20 | 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PUMF11 | NPN resistor-equipped transistor; PNP general purpose transistor | EndOfLife | |
PDTA143ZQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC143ET-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTA124EQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC144ET-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PUMH10-Q | NPN/NPN resistor-equipped double transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMD9-Q | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMD15-Q | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PIMP31-Q | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PUMD3-Q | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTD123YT-Q | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA143ZQC-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PUMB3H-Q | 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTC144EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTD114EU-Q | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTC124EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA114YQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PUMD13-Q | NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA123JQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC144EU-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PDTC114ET-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTC143XQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PUMH9-Q | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTC114YQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PUMB11-Q | 50 V, 100 mA PNP/PNP resistor-equipped double transistors; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTC124ET-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTD143ET-Q | 500 mA, 50 V NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PIMC32-Q | 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PBRP123YT-Q | 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PIMP32PAS-Q | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA114EU-Q | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTC123JU-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PDTC123YT-Q | NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC114YT-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PUMD16-Q | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 47 kΩ | Production | |
PDTA124XQB-Q | 50 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC143ZQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA114ET-Q | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PUMD48-Q | NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ and R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMD12-Q | NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PUMB2-Q | 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ | Production | |
PIMP32-Q | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PBRN113ET-Q | 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 1 kΩ | Production | |
PUMD2-Q | 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTC124EU-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PUMH13-Q | NPN/NPN double Resistor-Equipped Transistor (RET); R1= 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTC143EU-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ | Production | |
PDTC143ZU-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PIMP31PAS-Q | 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PBRN123YT-Q | 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PBRN113ZT-Q | 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PDTA123YQB-Q | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ | Production | |
PIMN32PAS-Q | 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTA124ET-Q | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PIMN31PAS-Q | 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PDTC124EQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC123YQB-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2: 10 kΩ | Production | |
PIMC32PAS-Q | 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ | Production | |
PDTC144EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143ZQB-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTC143EQC-Q | 50 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTC144EU-Q | 80 V, 100 mA NPN resistor-equipped transistor | Production | |
PUMH11-Q | 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PUMB13-Q | PNP/PNP resistor-equipped double transistors; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PUMH1-Q | NPN/NPN resistor-equipped double transistor; R1 = 22 kΩ, R2 = 22 kΩ | Production | |
PDTC114YU-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTC123JT-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ | Production | |
PUMH14-Q | 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open | Production | |
PDTB114EU-Q | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PQMH13-Q | NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PDTA115EU-Q | PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PUMD6-Q | 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1 = 4.7 kΩ, R2 = open | Production | |
PDTA143ZT-Q | 50 V, 100 mA PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
PIMC31PAS-Q | 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 1 kΩ, R2 = 10 kΩ | Production | |
PDTA143TU-Q | PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open | Production | |
NHUMD2-Q | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHUMH11-Q | 80 V, 100 mA NPN/NPN resistor-equipped double transistors | Production | |
NHUMD12-Q | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHUMD3-Q | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHUMH1-Q | 80 V, 100 mA NPN/NPN resistor-equipped double transistors | Production | |
NHUMH2-Q | 80 V, 100 mA NPN/NPN resistor-equipped double transistors | Production | |
PDTA123EU-Q | PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PUMD24-Q | 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
NHDTA114ET-Q | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTA144ET-Q | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTA124ET-Q | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTC115EU | 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC115ET | 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC123EM | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTC123EU | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTC123ET | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
NHUMB13-Q | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHUMB9-Q | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHUMB10-Q | 80 V, 100 mA PNP/PNP resistor-equipped double transistors | Production | |
NHDTC114YT-Q | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTC123JT-Q | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTC143ZT-Q | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
PDTA114YM | PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ | Production | |
PDTC115EU-Q | 50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ | Production | |
PDTC143ZT-Q | 50 V, 100 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ | Production | |
NHDTA143ZU-Q | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHDTA123JU-Q | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
NHUMD10-Q | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHUMD13-Q | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
NHDTC114EU-Q | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTC124EU-Q | 80 V, 100 mA NPN resistor-equipped transistors | Production | |
NHDTA114YU-Q | 80 V, 100 mA PNP resistor-equipped transistors | Production | |
PDTB113EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
NHUMD9-Q | 80 V, 100 mA NPN/PNP resistor-equipped double transistors | Production | |
PDTB123EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB143EU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB123YU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB114ET | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTB143XU | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTD113EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTB143XT | 50 V, 500 mA PNP resistor-equipped transistor | Production | |
PDTC143TT-Q | 50 V, 100 mA NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = open | Production | |
PDTD114ET | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ | Production | |
PDTD123YU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD123EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD113ZU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD143XT | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ | Production | |
PDTD143EU | 50 V, 500 mA NPN resistor-equipped transistor | Production | |
PDTD123ET-Q | 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ | Production | |
PDTD143XU | 50 V, 500 mA NPN resistor-equipped transistor | Production |
Application note (1) |
|||
---|---|---|---|
文件名称 | 标题 | 类型 | 日期 |
AN90024.pdf | Resistor Equipped Transistors (RETs): Key parameters and application insights | Application note | 2021-08-03 |
Brochure (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
Nexperia_document_brochure_DFN1412__diodes_transistors.pdf | DFN1412-6 - a new (double) package standard | Brochure | 2022-09-21 |
Marcom graphics (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
DFN1006B-3_SOT883B_mk.png | plastic, leadless ultra small plastic package; 3 solder lands; 0.35 mm pitch; 1 mm x 0.6 mm x 0.37 mm body | Marcom graphics | 2017-01-28 |
Selection guide (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
Nexperia_Selection_guide_2023.pdf | Nexperia Selection Guide 2023 | Selection guide | 2023-05-10 |
White paper (1) |
|||
文件名称 | 标题 | 类型 | 日期 |
Nexperia_document_whitepaper_RET_devices_2021.pdf | Nexperia document whitepaper RET devices 2021 | White paper | 2022-09-21 |
Frequently Asked Questions
A RET is a Resistor Equipped Transistor. RETs combine the bias resistor and bias-emitter resistor in the same package as the transistor. Double RETs are devices that combine two transistors and two matching bias resistors and bias-emitter resistors.
Transistors and resistors are combined in one package. This
- saves space
- reduces pick and place costs
- offers additional option for circuit design
- reduces bom costs
Resistor equipped transistors (RETs) are also known as:
- Digital transistors
- Pre-Bias transistors
- Built in resistor bipolar transistors
RETs can be used in:
- Low side switch
- High side switch
- Push pull stage
RETs are suitable for use in numerous applications including:
- Automotive
- Industrial and Power
- Communication
- And many more
Nexperia offers more than 400 parts to chose from including:
- 50 V RETs with 100 mA
- 50 V RETs with 500 mA
- 80 V RETs with 100 mA
- 40 V with 600mA Low VCEsat RETs (Performance based RETs (PBR))
Within Nexperia’s RET portfolio you will find single and dual RETs with a great variety of resistor combinations.
Nexperia RETs are available in a wide range of leaded and leadless SMD packages:
Standard leaded SMD packages like SOT23, SOT323, SOT457, SOT223 as well as leadless SMD packages like the very small DFN1006-3 and DFN packages with side-wettable flanks like DFN1110D-3 and DFN1412D-3
Most of our products are qualified to AEC-Q101, please always check the datasheet.
A voltage swing of approx. 1.2 V is sufficient for switching the RET. Therefore, RETs can be easily driven directly by a micro controller.
Nexperia RETs have a state-of-the-art ratio tolerance of down to +-10% (PBR)
Nexperia is offering 80 V RETs that provide enough headroom for use in 48 V automotive board net (e.g. mild hybrid and EV cars) and other higher voltage circuits which are often subject to large spikes and pulses that previous 50 V parts cannot handle. The new series (NHDTx and NHUMx) includes 42 parts with PNP / NPN combinations. These come with the same bias resistor combinations as Nexperia’s 50 V parts. Devices have a 100 mA current capability and are AEC-Q101-approved.
