USB-Type-C AC/DC壁式充电器

USB供电(PD)架构非常适合端到端电源支持,并且可通过设备的USB端口实现快速充电。USB PD并不局限于USB电池充电,它允许高达100 W充电、电源支持和角色切换,以实现系统电源优化。该连接器提供的电压范围为5.0 V(2.0 A,适用于手持式设备和可穿戴设备)至20 V(5.0 A,适用于超级本)

功能框图

Highlighted components are Nexperia focus products

设计考虑因素

提供USB PD标准中定义的多种输出电压

快速充电

支持国际能源法规,如能源之星

USB性能可扩展性
