与门

布尔逻辑与功能采用多种技术和封装

我们提供多种技术和封装选项,确保您能够轻松找到适合您系统的与门。所有器件均提供可靠性能和强大功能,可帮助您充分发挥应用潜力。

主要特性和优势

  • 5 V和3.3 V混合型应用
  • 缩短复杂设计上市的时间
  • 节省电路板空间
  • 开漏输出选项
  • 在复杂布局中具有更出色的信号完整度
  • 宽电源电压范围
  • 低传播延迟
  • 过压容限选项
  • 低输入阈值选项
  • CMOS低功耗

关键应用

  • 手机
  • 计算
  • 机顶盒
  • 液晶电视
  • 工业控制器
